Lenze ECS series User Manual

Monitoring functions
Configuring monitoring functions
DC−bus voltage monitoring (OU, LU)
10

219
EDBCSXA064 EN 3.2
Selection Mains voltage
Brake unit
LU message
(Undervoltage)
OU message
(Overvoltage)
C0173 Power supply module
[V AC]
Setting
[V DC]
Resetting
[V DC]
Setting
[V DC]
Resetting
[V DC]
0 230 yes/no 130 275 400 390
1 400 yes/no 285 430 800 790
2 400 ... 460 yes/no 328 473 800 790
3 480 no 342 487 800 785
4 480 yes 342 487 800 785
10 230 yes/no C0174 C0174 + 5 V 400 390
11 400 (Lenze setting) yes/no C0174 C0174 + 5 V 800 790
12 400 ... 460 yes/no C0174 C0174 + 5 V 800 790
13 480 no C0174 C0174 + 5 V 800 785
14 480 yes C0174 C0174 + 5 V 800 785
 Tip!
If undervoltage is existent for more that 3 s, or if mains connection is carried
out, an entry into the fault memory is effected.
ƒ This operational mode can occur if the control module is fed via the
terminals X6/+24 and X6/GND by means of an external supply and the
mains are disconnected.
ƒ If there is no undervoltage anymore (mains are reconnected again), the
entry in the fault memory is not continued, but deleted. This case does not
describe an error, but a state of the drive controller.
Undervoltages of less than 3 s are interpreted as a fault (e. g. mains fault) and
are entered into the fault memory. In this case, the fault memory is updated.
