Lenze ECS series User Manual

Troubleshooting and fault elimination
Fault messages
Overview of fault messages, error sources and responses
12

244
EDBCSXA064 EN 3.2
System error message Possible settings/response
· Lenze setting
ü Setting possible
Available in
No. Display Source Meaning
Code TRIP Messa
ge
Warni
ng
FAIL−Q
SP
Off Drive
PLC
Servo
PLC
ECSxA
x122 CE11
FIF−CAN
1
FIF−CAN1_IN (monitoring
time can be set with
C2457/1)
C0591 ü ü · ü
CAN−au
x1
CANaux1_IN (monitoring
time can be set with
C2457/1)
C2481 ü ü · ü
x123 CE12
FIF−CAN
2
FIF−CAN2_IN (monitoring
time can be set with
C2457/2)
C0592 ü ü · ü
CAN−au
x2
CANaux2_IN (monitoring
time can be set with
C2457/2)
C2482 ü ü · ü
x124 CE13
FIF−CAN
3
FIF−CAN3_IN (monitoring
time can be set with
C2457/3)
C0593 ü ü · ü
CAN−au
x3
CANaux3_IN (monitoring
time can be set with
C2457/3)
C2483 ü ü · ü
x125 CE14
FIF−CAN BUS−OFF status of FIF−CAN
(too many faulty telegrams
received)
C0595 ü ü · ü
CAN−au
x
BUS−OFF state CAN AUX
(too many faulty telegrams
received)
C2484 ü ü · ü
x126 CE15 CAN−au
x
Communication error of
gateway function (C0370,
C0371) via CAN−AUX
C2485 ü ü · ü
x190 nErr MCTRL Speed beyond tolerance
margin (C0576)
C0579 ü ü ü ü · ü ü
x200 NMAX MCTRL Maximum speed exceeded
(C0596)
· ü ü
x201 overrun Task1
Internal
Task with ID 2
2)
· ü ü ü ü ü
x202 overrun Task2 Task with ID 3
x203 overrun Task3 Task with ID 4
x204 overrun Task4 Task with ID 5
x205 overrun Task5 Task with ID 6
x206 overrun Task6 Task with ID 7
x207 overrun Task7 Task with ID 8
x208 overrun Task8 Task with ID 9
x219 overrun Cycl.−T Internal Time−out in cyclic task
(PLC_PRG, ID 1)
2)
· ü ü ü ü ü
x: 0 = TRIP, 1 = Message, 2 = Warning, 3 = FAIL−QSP
2)
Can be set in DDS under Project  Exception handling
