System modules
DIGITAL_IO (node number 1)
Outputs_DIGITAL (digital outputs)
13

346
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0118 Polarity of the digital outputs
 345
 129
1 DIGOUT pol 0 HIGH level active X6/DO1 (DIGOUT_bOut1_b)
2 DIGOUT pol 0 HIGH level active X25 (DIGOUT_bRelais_b, brake
connection)
0 HIGH level active
1 LOW level active
C0444 Status of the digital outputs
Only display
 345
1 DIS: DIGOUT 0 1 Status of the digital output
X6/DO1
2 DIS: DIGOUT Relay control status
C0602 MONIT REL1 3
Fault response − open circuit
monitoring of relay output X25
0 TRIP
2 Message
3 Off
4 FAIL−QSP
Terminal assignment
Digital
inputs
Function Electrical data
X6 Digital output
24 V DC
0.7 A (max. 1.4 A)
short−circuit−proof
X6/DO1 Digital output 1
X6 Output "safe torque off" (former "safe standstill")
X6/SO Output feedback
LOW During operation
HIGH "Safe torque off" (former
"safe standstill") active
X25 Connection motor holding brake
23 ... 30 V DC;
max. 1.5 A
Set the brake voltage so that the
permissible voltage at the brake
will not be exceeded or the values
do not fall below the threshold!
X25/B1 Brake connection +
X25/B2 Brake connection −
X6 Low−voltage supply motor holding brake
X6/B+ Brake supply +
X6/B− Brake supply −
