System modules
FCODE_FreeCode (node number 141)
13
350
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0250 FCODE 1 Bit 0
Freely selectable digital signal
(1 bit)
347
0 1
C0470 Freely configurable code for
digital signals
Hexadecimal value is bit−coded.
347
1 FCODE 8bit 0 00 {hex} FF C0470/1 = C0471, bit 0 ... 7
2 FCODE 8bit 0 C0470/2 = C0471, bit 8 ... 15
3 FCODE 8bit 0 C0470/3 = C0471, bit 16 ... 23
4 FCODE 8bit 0 C0470/4 = C0471, bit 24 ... 31
C0471 FCODE 32bit 0
Hexadecimal 32−bit
interpretation of C0470
347
0 {1} 4294967295
C0472 FCODE analog Freely configurable code for
relative analog signals
347
1 0.0 −199.99 {0.01 %} 199.99 FCODE_bC472_1_a
2 0.0 FCODE_bC472_2_a
3 100.0 FCODE_bC472_3_a
4 0.0 FCODE_bC472_4_a
... ... ...
20 0.0 FCODE_bC472_20_a
C0473 Freely configurable code for
absolute analog signals
347
1 FCODE abs 1 −32767 {1} 32767
2 FCODE abs 1
3 FCODE abs 0
... ... ...
10 FCODE abs 0
C0474 Freely configurable code for
phase signals
347
1 FCODE PH 0 −2147483647 {1} 2147483647
... ... ...
5 FCODE PH 0
C0475 Freely configurable code for
phase difference signals
347
1 FCODE DF 0 −16000 {1 rpm} 16000
2 FCODE DF 0
