System modules
MCTRL_MotorControl (node number 131)
Adjusting the motor data
13
368
EDBCSXA064 EN 3.2
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0097
DIS:Lt−Ident
0
Power stage identification
0
{1}
255
C0110
Service Code
Fine adjustment − mutual
inductance
50
{1 %}
200
C0111
Service Code
Fine adjustment − rotor
resistance
50.00
{1 %}
199.99
C0112
Service Code
Fine adjustment − rotor time
constant
50
{1 %}
200
C0113
Service Code
Fine adjustment − magnetising
current (I
sd
)
50
{1 %}
200
367
