Lenze ECS series

System modules
MCTRL_MotorControl (node number 131)
Monitoring
13

370
EDBCSXA064 EN 3.2
No. of the fault message Type of response
0xxx TRIP
1xxx Message
2xxx Warning
3xxx FAIL−QSP (only for ECSxS/P/M/A axis modules)
Example: C0168/1 = 2061
ƒ x061:
The current fault (subcode 1 of C0168) is a communication error (fault message
"CE0"/no. "x061") between the AIF module and the ECS axis module.
ƒ 2xxx:
The fault response is a warning.
 Note!
An overview of the monitoring function is provided in chapter "10.2
Monitoring functions" ( 198).
The monitoring responses are described in the same chapter ( 202).
 Tip!
Occurring faults generally do not affect the operating ability of the PLC!
