Lenze ECSEE040 - Page 138

Appendix
Code list
11

138
EDBCSXE040 EN 6.0
Parameter
C0125
Designation
LECOM baud rate (AIF)
Data type: INTEGER_32
Index: 24450
dec
= 5F82
hex
Baud rate for operation via AIF interface
Selection list (Lenze setting printed in bold) Information
0 9600 bits/s
1 4800 bits/s
2 2400 bits/s
3 1200 bits/s
4 19200 bits/s
Parameter
C0126
Designation
Response of AIF communication monitoring (CE0)
Data type: UNSIGNED_32
Index: 24449
dec
= 5F81
hex
Response in the case of a communication error on the AIF interface (CE0 fault message)
Selection list (Lenze setting printed in bold) Information
0 TRIP
3 No response
Parameter
C0127
Designation
Function of integrated brake transistor
Data type: INTEGER_32
Index: 24448
dec
= 5F80
hex
Activation of brake chopper IGBT/fast discharge function (short−circuit braking)
 63
Selection list (Lenze setting printed in bold) Information
0 Brake chopper and short−circuit
braking
1 Only brake chopper
2 Only fast discharge function
(short−circuit braking)
4 Without function
Parameter
C0130
Designation
Control word "CTRL1" to power supply module
Data type: UNSIGNED_16
Index: 24445
dec
= 5F7D
hex
Bit coded display of control word "CTRL1" to the power supply module
 105
Display range (min. value | unit | max. value)
0x0000 0xFFFF
Bits (read only) Information
Bit 0 Toggle bit
Bit 1 TRIP−RESET (low active)
Bit 2 Fast discharge (short−circuit
braking)
Bit 3 Central controller enable (for the
axis modules via output X6/DO1)
Bit 4
Not assigned
...
Bit 7
Bit 8
Reserved
...
Bit 10
Bit 11
Not assigned
...
Bit 15
