Appendix
Code list
11
139
EDBCSXE040 EN 6.0
Parameter
C0131
Designation
Status word 1 "Stat1" from power supply module
Data type: UNSIGNED_16
Index: 24444
dec
= 5F7C
hex
Bit coded display of the status word 1 "Stat1" from the power supply module
106
Display range (min. value | unit | max. value)
0x0000 0xFFFF
Bits (read only) Information
Bit 0 Ready for operation (RDY)
Bit 1 Warning is active
Bit 2 Message is active
Bit 3 TRIP is active
Bit 4 Quick discharge (short−circuit
braking)not possible
Bit 5 Quick discharge (short−circuit
braking)I active
Bit 6 −UG relay closed
Bit 7 +UG relay closed
Bit 8
Reserved
...
Bit 10
Bit 11 Power supply enable status X6/DI1
Bit 12 Controller enable status X6/DI2
Bit 13 Feedback of received toggle bit
Bit 14 Not assigned
Bit 15 Not assigned
Parameter
C0132
Designation
Status word 2 "Stat2" from power supply module
Data type: INTEGER_32
Index: 24443
dec
= 5F7B
hex
The current fault number is transferred in status word 2.
131
Display range (min. value | unit | max. value)
−2147483647 2147483647
