Appendix
Code list
11
140
EDBCSXE040 EN 6.0
Parameter
C0150
Designation
DCTRL status word 1
Data type: UNSIGNED_16
Index: 24425
dec
= 5F69
hex
Bit coded display of the internal status word 1
Display range (min. value | unit | max. value)
0x0000 0xFFFF
Bits (read only) Information
Bit 0 Discharge DC bus (U
G
< 60 V)
Bit 1 Pulse inhibit (IMP)
Bit 2 I
max
limit current reached
Bit 3 Charging of the DC bus completed
Bit 4 Heatsink fan on/off l 1 = the heatsink fan is switched on if the
temperature of the heatsink or the device interior
exceeds 50°C.
l 0 = the heatsink fan is switched off if the
temperature of the heatsink or the device interior
falls below 45°C.
Bit 5 I x t−warning active
Bit 6 I x t−limit reached
Bit 7 Controller inhibit (CINH)
Bit 8 Status code (binary, LSB)
Bit 9 Status code (binary)
Bit 10 Status code (binary)
Bit 11 Status code (binary, MSB)
Bit 12
Not assigned
...
Bit 15
Parameter
C0151
Designation
DCTRL status word 2 (high word)
Data type: UNSIGNED_16
Index: 24424
dec
= 5F68
hex
Bit coded display of the internal status word 2
Display range (min. value | unit | max. value)
0x0000 0xFFFF
Bits (read only) Information
Bit 0
Not assigned
...
Bit 3
Bit 4 Fault/TRIP active
Bit 5 Short−circ. brake TRIP active
Bit 6 Not assigned
Bit 7 LP1 warning active
Bit 8 Power system ready (DC bus can be
charged)
Bit 9 No earth fault
Bit 10 Heatsink fan fault (FAN)
Bit 11 DC bus is charged externally
Bit 12
Not assigned
...
Bit 15
