Appendix
Code list
11

141
EDBCSXE040 EN 6.0
Parameter
C0161
Designation
Current TRIP fault
Data type: INTEGER_32
Index: 24414
dec
= 5F5E
hex
Display of the current TRIP fault (TRIP, short−circuit brake TRIP)
 131
Parameter
C0168
Designation
Fault history buffer
Data type: INTEGER_32
Index: 24407
dec
= 5F57
hex
List of the fault messages occurred (TRIP, short circuit braking TRIP, message, warning)
 130
 131
Subcodes Information
C0168/1 Currently active fault message
C0168/2 Last fault message
C0168/3 Second to last fault message
C0168/4 Third to last fault message
C0168/5 Fourth to last fault message
C0168/6 Fifth to last fault message
C0168/7 Sixth to last fault message
C0168/8 Seventh to last fault message
Parameter
C0169
Designation
Fault memory time
Data type: INTEGER_32
Index: 24406
dec
= 5F56
hex
Time at which the fault messages entered in the history buffer (C0168) occurred.
l Respective status of the operating hour counter C0179
Display range (min. value | unit | max. value)
−214748 214748
Subcodes Information
C0169/1 Currently active fault message
C0169/2 Last fault message
C0169/3 Second to last fault message
C0169/4 Third to last fault message
C0169/5 Fourth to last fault message
C0169/6 Fifth to last fault message
C0169/7 Sixth to last fault message
C0169/8 Seventh to last fault message
Parameter
C0170
Designation
Fault counter
Data type: INTEGER_32
Index: 24405
dec
= 5F55
hex
Frequency at which the fault messages entered in the history buffer (C0168)) occurred.
Display range (min. value | unit | max. value)
0 65535
Subcodes Information
C0169/1 Currently active fault message
C0169/2 Last fault message
C0169/3 Second to last fault message
C0169/4 Third to last fault message
C0169/5 Fourth to last fault message
C0169/6 Fifth to last fault message
C0169/7 Sixth to last fault message
C0169/8 Seventh to last fault message
