Lenze EPM-H505 - Project transfer to the operating unit

Commissioning
Project transfer to the operating unit
Connecting operating unit and PC
5

68
EDBPM−H505 DE/EN/FR 6.1
5.2 Project transfer to the operating unit
5.2.1 Connecting operating unit and PC
 Stop!
Only connect PC and operating unit when the units are switched off!
Operating unit EPM−H505
l
HMI Designer
0
1
INPUT VOLTAGE: 18-32 VDC 10 W
FUSE 800 mA
+24 VDC
0 VDC
1
2
3
4
N. C.
MSP
N.C.
CAN+
Shield
CAN-
V-
1234 5
1234
h505_003
Fig. 5−1 Connect EPM−H505 operating unit and PC
ƒ EPZ−H110 download cable  on the MSP interface at the operating unit and
COM1 or COMx on the PC 
