2.1.4 Menu structure
For easy operation the codes are divided in two groups:
z The menu user
– is active after every mains switching or keypad attachment during operation.
– contains all codes for a standard application with linear V/f characteristic control (Lenze
setting).
– can be modified as required under C0517.
z The menu all
– contains all codes.
– shows a list of all codes in ascending order.
2.2 The menu u
uu
us
ss
se
ee
er
rr
r - The 10 most important drive parameters
After mains switching or plugging in the keypad during operation, the 10 codes defined in code
C0517 are immediately available.
Indefault setting themenuuser contains all codes required for a standard application with linear V/f
characteristic control.
Code Name Lenze setting
C0050 Output frequency Display: Output frequency without slip compensation
C0034 Setpoint selection range 0 Standard I/O X3/8: 0 ... 5 V / 0 ... 10 V / 0 ... 20 mA
C
0
0
3
4
S
e
t
p
o
i
n
t
s
e
l
e
c
t
i
o
n
r
a
n
g
e
0
Application I/O
X3/1U: 0 ... 5 V / 0 ... 10 V
X3/2U: 0 ... 5 V / 0 ... 10 V
C0007 Fixed configuration of digital inputs 0 E4 E3 E2 E1
C
0
0
0
7
F
i
x
e
d
c
o
n
f
i
g
u
r
a
t
i
o
n
o
f
d
i
g
i
t
a
l
i
n
p
u
t
s
0
CW/CCW DCB JOG2/3 JOG1/3
CW/CCW rotation DC injection brake Selection of fixed setpoints
C0010 Minimum output frequency 0.00 Hz
C0011 Maximum output frequency 50.00 Hz
C0012 Acceleration time main setpoint 5.00 sec
C0013 Deceleration time main setpoint 5.00 sec
C0015 V/f rated frequency 50.00 Hz
C0016 V
min
boost Depending on the controller
C0002 Parameter set ma nagement Restore default setting; Transfer parameter sets with keypad; save, load or copy own
basic settings


 Note!
Use C0002 ”Parameter set transfer/restorage of default setting” to transfer
configurations from one controller to the other with keypad or restore the default
setting by loading the Lenze setting (e.g. if you lost track during parameter setting).
