Lenze i700 Series

Technical data
Rated data
External supply voltage 24 V
4
l
32
EDS700ACBA EN 5.1
Current consumption of the devices from the 24 V voltage supply:
I
r24
P
24
I
max24
C
L
Terminal
[A] [W] [A] [mF]
E70ACPSx0304x 0.5 12 1.5
500 X21
E70ACPSx0604x 0.5 12 1.5
E70ACMxx0054xx1xxx 0.5 12 1.0
3000 X3
E70ACMxx0104xx1xxx 0.6 14 1.0
E70ACMxx0204xx1xxx 0.6 14 1.0
E70ACMxx0324xx1xxx 1.0 24 2.0
E70ACMxx0484xx1xxx 1.0 24 2.0
E70ACMxx0644xx1xxx 1.2 29 2.0
E70ACMxx0054xx2xxx 0.8 19 1.0
E70ACMxx0104xx2xxx 0.8 19 1.0
E70ACMxx0204xx2xxx 1.0 24 2.0
E70ACMxx0324xx2xxx 1.4 34 2.0
I
r24
Rated current of the device for 24 V supply
P
24
Rated power of the device for 24 V supply
I
max24
Maximum device current for the 24 V supply (during start−up of the internal
fans, up to 0.5 s)
C
L
Charging capacity of the device for 24−V supply
