6 Electrical installation
Communication via the diagnostic interface (Servo Drives 9400)
EDKMF2181 DE/EN/FR/ES/IT 3.0 50

H1_E_INST-SteckerFederkraftAnschluss FKCT
Installation steps
Step Description Connection
(see graphic)
Additional
information
1. Connect the diagnostic interface to the Servo Drives
9400 (use prefabricated cable)

56
2. If it is not possible to use the internal modem, connect
an external modem.

59
3. Connect the controller to the CAN bus.

-
4. Connect the ModemCAN 2181 to the telephone network.

57
5. Connect the voltage supply to the plug connector.

60
