Lenze L-force Communication ModemCAN EMF2181IB - Telephone Connection

Electrical installation
Telephone connection
6
EDKMF2181 DE/EN/FR/ES/IT 3.0 57

H1_E_INST-SteckerFederkraftAnschluss FKCT
Telephone connection
 Note!
Use one of the prefabricated telephone cables included in the scope of supply
of the communication module.
Assignment of the telephone socket
2181FEW003C
Pin Designation
2 not assigned
3 L
a
(TIP)
4 L
b
(RING)
5 not assigned
