Torque plate on threaded pitch circle
g500-B45 ...B110
Gearbox Dimensions Mass
a
4
a
8
a
9
d D p
8
p
9
k
6
m
mm mm mm mm mm mm mm mm kg
g500-B45 12.0 100 8.0 8.0 20.0 115 42.0 9.0 0.3
g500-B110 13.0 110 9.0 10.0 25.0 128 54.0 11.0 0.5
Product extensions
T
orque plates
