H264 NVR User’s Guide
23
Enable
Choose Enable to make sure all UPNP settings available.
HTTP
Route will automatically distribute HTTP port for the
device, when IE viewing, it need this port(eg.
60.12.9.26:66)
TCP
Router will automatically distribute TCP port for the
device, when monitoring via CMS, it need this port.
Mobile Port
Router will automatically distribute Mobile Port for the
device, when mobile monitor, it need this port.
FTP
File Transfer Protocol (FTP) is a standard network protocol used to transfer
files from one host to another host over a TCP-based network, such as the
Internet.
Enable
Choose Enable to make sure all FTP settings available.
Server IP
Input FTP server IP address
Port
FTP server port number
User Name
Input User name
Password
Input the password corresponding to the user.
Anonymous
Select anonymous or not
DirName
Specify the file path
