LESER Global Standard
Assembly instructions for type 526 API
LGS 4104
Page 29/45
disclosure cat.:
II
proofread:
SSt
published date:
06/14/18
effect. date:
05/18
author:
Nieh
released by:
KUW
replaces:
initial
status:
Published
resp. depart.:
IE
date of release:
06/14/18
revision No.:
2
doc. type:
LGS
change rep. No.:
NA
retention period:
10
protected
Illustration
Description
Aids / Tools
Figure 9.8-4
Grease adjusting screw
Brush
Assembly
grease
(Molykote
Paste)
Figure 9.8-5
Screw the adjusting screw
into the bonnet until
resistance from the spring is
felt.
