Leser 526 API User Manual

LESER Global Standard
Assembly instructions for type 526 API
LGS 4104
Page 5/45
disclosure cat.:
II
proofread:
SSt
published date:
06/14/18
effect. date:
05/18
author:
Nieh
released by:
KUW
replaces:
initial
status:
Published
resp. depart.:
IE
date of release:
06/14/18
revision No.:
2
doc. type:
LGS
change rep. No.:
NA
retention period:
10
protected
8 Preparation for valve assembly
8.1 Emboss the punch numbers (if requested in the order).
Illustration
Description
Aids / Tools
Figure 8.1-1
Emboss the code into the
edge of the outlet flange
(position of the code as
per the work plan).
Hammer
Punch numbers
9 Assembly of type 526
9.1 Assembly of the nozzle and blow down ring
Illustration
Description
Aids / Tools
Figure 9.1-1
Grease sealing surface
Brush
Assembly
grease
(Molykote
Paste)
