LESER Global Standard
Assembly instructions for type 526 API
LGS 4104
Page 8/45
disclosure cat.:
II
proofread:
SSt
published date:
06/14/18
effect. date:
05/18
author:
Nieh
released by:
KUW
replaces:
initial
status:
Published
resp. depart.:
IE
date of release:
06/14/18
revision No.:
2
doc. type:
LGS
change rep. No.:
NA
retention period:
10
protected
Figure 9.3-2
Grease a spacer ring for
each of the screws and put
on as a seal.
Illustration
Description
Aids / Tools
Figure 9.3-3
Screw the locking screw into
the back section of the body
and tighten.
Open-end
spanner
Figure 9.3-4
Screw the screw plug into
the side of the body and
tighten.
Open-end and
ring spanner
