Functions
Leuze electronic MLC 510 14
4 Functions
An overview of features and functions of the safety sensor can be found in chapter “Device descrip-
tion” (see chapter 3.1 "Device overview of the MLC family").
Overview of functions
Range reduction
Transmission channel changeover
4.1 Transmission channel changeover
Transmission channels are used to prevent mutual interference of safety sensors which are located close
to each other.
NOTICE
To guarantee reliable operation, the infrared beams are modulated so they can be discerned
from the ambient light. Welding sparks or warning lights, e.g. from passing high-lift trucks,
thereby do not influence the protective field.
With the factory setting, the safety sensor works in all operating modes with transmission channelC1.
The transmission channel of the transmitter can be switched by changing the supply voltage polarity (see
chapter 7.1.1 "MLC500 transmitter and MLC502 transmitter").
The transmission channel of the receiver can be switched by changing the supply voltage polarity (see
chapter 7.1.2 "MLC510 receiver").
NOTICE
Faulty function due to incorrect transmission channel!
Select the same transmission channel on the transmitter and corresponding receiver.
4.2 Operating range selection
In addition to selecting the suitable transmission channels (see chapter 4.1 "Transmission channel
changeover"), the operating range selection also serves to prevent mutual interference of adjacent safety
sensors. At reduced operating range the light power of the transmitter reduces, so that around half of the
nominal range is reached.
Select operating range:
Ä Wire pin4 (see chapter 7.1 "Pin assignment transmitter and receiver").
ð The wiring of pin4 determines the transmitting power and thereby the range.
WARNING
Impairment of the protective function due to incorrect transmitting power!
The light power emitted from the transmitter is reduced through a single channel and without
safety-relevant monitoring.
Ä Do not use this configuration option for safety purposes.
Ä Note that the distance to reflective surfaces must always be selected so that no reflection
bypass can occur even at maximum transmitting power (see chapter 6.1.4 "Minimum dis-
tance to reflective surfaces").
