About this document
Leuze electronic MLC 510 5
1 About this document
1.1 Used symbols and signal words
Tab.1.1: Warning symbols and signal words
Symbol indicating dangers to persons
Symbol indicating possible property damage
NOTE Signal word for property damage
Indicates dangers that may result in property damage if the measures for dan-
ger avoidance are not followed.
CAUTION Signal word for minor injuries
Indicates dangers that may result in minor injury if the measures for danger
avoidance are not followed.
WARNING Signal word for serious injury
Indicates dangers that may result in severe or fatal injury if the measures for
danger avoidance are not followed.
DANGER Signal word for life-threatening danger
Indicates dangers with which serious or fatal injury is imminent if the measures
for danger avoidance are not followed.
Tab.1.2: Other symbols
Symbol for tips
Text passages with this symbol provide you with further information.
Symbol for action steps
Text passages with this symbol instruct you to perform actions.
Symbol for action results
Text passages with this symbol describe the result of the preceding action.
Tab.1.3: Terms and abbreviations
Response time The response time of the protective device is the maximum time between the
occurrence of the event that results in activation of the safety sensor and the
provision of the switching signal at the interface of the protective device (e.g.,
OFF state of the OSSD pair).
AOPD Active Optoelectronic Protective Device
(Active Optoelectronic Protective Device)
ESPE Electro-sensitive protective equipment
LED LED, display element in transmitter and receiver
MLC Brief description of the safety sensor, consisting of transmitter and receiver
MTTF
d
Mean time to dangerous failure
(Mean Time To dangerous Failure)
OSSD Safety-related switching output
(Output Signal Switching Device)
PFH
d
Probability of a dangerous failure per hour
(Probability of dangerous Failure per Hour)
