Order guide and accessories
Leuze electronic MLC 510 55
Tab.15.2: Part descriptions, examples
Examples for part desig-
nation
Properties
MLC500T14-600 Type4 transmitter, PLe, SIL3, resolution 14mm, protective field height
600mm
MLC500T30-900 Type4 transmitter, PLe, SIL3, resolution 30mm, protective field height
900mm
MLC502T30-900 Transmitter with external test input, type4, PLe, SIL3, resolution 30mm,
protective field height 900mm
MLC510T90-1500 Type4 Basic receiver, PLe, SIL3, resolution 90mm, protective field height
1500mm
Scope of delivery
• Transmitter including 2sliding blocks, 1instruction sheet
• Receiver including 2sliding blocks, 1self-adhesive notice sign “Important notices and notices for the
machine operator”, 1set of connecting and operating instructions (PDF file on CD-ROM)
Tab.15.3: Part numbers of MLC 500 transmitter depending on resolution and protective field height
Protective field
height hhhh
[mm]
14mm
MLC500T14-
hhhh
20mm
MLC500T20-
hhhh
30mm
MLC500T30-
hhhh
40mm
MLC500T40-
hhhh
90mm
MLC500T90-
hhhh
150 68000101 68000201 68000301 68000401 -
225 - 68000202 68000302 68000402 -
300 68000103 68000203 68000303 68000403 -
450 68000104 68000204 68000304 68000404 68000904
600 68000106 68000206 68000306 68000406 68000906
750 68000107 68000207 68000307 68000407 68000907
900 68000109 68000209 68000309 68000409 68000909
1050 68000110 68000210 68000310 68000410 68000910
1200 68000112 68000212 68000312 68000412 68000912
1350 68000113 68000213 68000313 68000413 68000913
1500 68000115 68000215 68000315 68000415 68000915
1650 68000116 68000216 68000316 68000416 68000916
1800 68000118 68000218 68000318 68000418 68000918
1950 68000119 68000219 68000319 68000419 68000919
2100 68000121 68000221 68000321 68000421 68000921
2250 68000122 68000222 68000322 68000422 68000922
2400 68000124 68000224 68000324 68000424 68000924
2550 68000125 68000225 68000325 68000425 68000925
2700 68000127 68000227 68000327 68000427 68000927
2850 68000128 68000228 68000328 68000428 68000928
3000 68000130 68000230 68000330 68000430 68000930
