24Fast /2 Gigabit Ethernet combo Web Smart Switch
Diagnosing LED Indicators
The Switch can be easily monitored through panel indicators to assist in identifying
problems, which describes common problems you may encounter and where you can
find possible solutions.
IF the power indicator does turn on when the power cord is plugged in, you may have a
problem with power outlet, or power cord. However, if the Switch powers off after
running for a while check for loose power connections, power losses or surges at
power outlet. IF you still cannot resolve the problem, contact your local dealer for
assistance.
Cabling
RJ-45 ports:
use unshielded twisted-pair (UTP) or shield twisted-pair ( STP ) cable for
RJ-45 connections: 100
Ω
Category 3, 4 or 5 cable for 10Mbps connections or 100
Ω
Category 5 cable for 100Mbps connections. Also be sure that the length of any
twisted-pair connection does not exceed 100 meters (328 feet). Gigabit port should
use Cat-5 or cat-5e cable for 1000Mbps connections. The length does not exceed 100
meters.
Mini GBIC not function
When you have installed the Mini GBIC module into the switch, but the switch didn’t
detect the Mini GBIC module. Following the below steps to solve the problem.
Power off the switch.
Disconnect the Giga copper connection.
Remove the Mini GBIC module from the switch.
Reinstall the Mini GBIC module into the switch.
Power on the switch
Plug in the cable into Mini GBIC port
Check the LED status is normal or not
49
