13
Reset
Press the buttons of “Shutdown” and “Backup”
simultaneously for 6 seconds to reset the system
setting to factory default.
Rear Ports:
Ports
Description
Antenna
Connect 2.4GHz dipole antenna.
LAN
Automatically MDI / MDIX LAN port can sense the
cable type when connecting to Ethernet-enabled
computer, network of hub, switch, or router.
USB1 / USB2
The ports where you can connect to USB disk, digital
camera, or card reader.
Card reader:
* Memory card must insert to card reader first before
connect to the storage device.
* Storage device supports one memory card at a
time. Please do not insert multiple memory cards into
the card reader.
Power Switch
Switch on/off the device.
Power Jack
12V / 4A power inlet.
