15
Baery placed on the rear side
of the seat tube
Chilo, Tumbi
Switching on: Switch the baery using a switch on its upper part.
Manipulation: Remove the seatpost with saddle first to be able to remove the baery from the
frame. The lock is located in the lower part of the baery. Then, turn the clock into the UNLOCK
position, and remove the baery by pulling its handle up.
The baery is installed in reverse order. The groove of the baery must be placed onto the guiding
ledge, otherwise it will be impossible to slide it down completely. Slide the baery carefully, so that
its connector is not damaged by a sharp impact. Turn the key to the LOCK position to secure the
baery. Remove the key.
How to find out about capacity of the baery: by the means of a LED indicator located in the
upper part of the baery. It is activated by pushing the buon. The baery must be switched on.
The baery is at its full capacity if 4 LED diodes are lit (3 green, 1 red). If only red LED diode is on,
the baery is nearly depleted, and must be recharged as soon as possible.
Baery charging
RECOMMENDATION Lithium baeries do not have the memory eect, so they can be
charged any time, ideally aer every ride. Due to self-acting discharge of the baery that
causes gradual loss of capacity, it is recommended to check the baery regularly during a
long-term storage, and to recharge the baery if a drop below the recommended level of
60-80% of the its full capacity is found out.
Baery can be recharged both either directly on the bicycle, or it can be removed and recharged
separately from the e-bike. Always switch the baery o before recharging it. Baery must be
always charged in dry environment. The charging connector is not resistant to splashing water.
Room temperature (15–20°C) is ideal for baery recharging. Recharging the baery in ambient
temperature lower than 0°C or higher than 40°C may seriously damage the baery.
battery status
locked
unlocked
baery o
