CODAC – e-bike control
Calvia HD, Chilo 1, Muan HD, Musca HD
speed units
Walk assistance
Speed / distance
units
power indicator
assistance mode
baery status
lights
speed indicator
displaying of additional
information
additional information
display modeí
Error messages
USB slot
Switching On/Off
1. Switch on the electric system power on the battery
Activate the baery by pushing the buon on its housing.
2. Switch on the LCD panel of the e-bike.
Push the X buon on the display control and hold it
pushed for 5 seconds. The electric system is switched o
in the same way. Hold the buon pushed for 4 seconds to
switch o the frame baery. The system will automatically
switch o aer 10 minutes of inactivity to save energy.
Setting the assistance mode
To change assistance mode in the range of 0-5, briefly push the buon. The highest level
of assistance is indicated with the number 5, the level with indication 0 means no assistance of
the motor.
WARNING The motor may vibrate for a short period of time during a low revolution ride
with a high degree of assistance set. If this happens, we recommend that you immediately
change the assistance mode to a lesser degree.
Walk Assistance
Walk Assistance is activated by pushing and holding the (-) buon on the control display.
The assistance mode ranging from 1 to 5 must be selected to activate the Walk Assistance mode.
The purpose of this function is to make manipulation with the e-bike easier for its users. Typically, it
is used during walking with the e-bike. In this case, the e-bike speed will be between 4 and 6km/h.
The Walk Assistance is disabled immediately aer you release the buon.
Baery placed on
the rear side of
the seat tube
integrovaná
baterie
