3 TOOLS NEEDED
6
Tools required:
• Wire stripper
• Adjustable Wrench M6
• Voltmeter or digital multimeter (for measuring AC voltage at the installation site)
• Level
• Pencil or marker
• Drill
# Product Name Quantity Description
1 AC Charger 1 With attached input power cable and output charging cable.
2
User Manual 1 PDF version available online.
3 Wall Mounted Bracket 1 For mounting the charging station to the wall/structure.
4 M5 Anti-Theft Round Head Screws 2 For securing the charging station to the Mounting Bracket.
5 M6 Hexagonal Expansion Screws 4 For installing the Mounting Bracket to the wall/structure.
6 Standard RFID Card 2 RFID version only.
7 Admin RFID Card 1 RFID version only.
8 Allen Wrench 1 For tightening M5 Screws.
9 Corrugated Mounting Template 1 For easy drilling of 4 screws holes for wall-mounted bracket.
10 Wing Nut Screw 2
For securing the rear notch of the charger to the
wall-mounted bracket.
Contents Included:
14
78910
253
6
Electric Vehicle AC Charger
Instalation Instructions
Standard: Admin:
Wall Mounted Bracket
