5 DIMENSIONS
8
Enclosure
Wall-Mounted Bracket
3.15 in.
4-Φ0.35 in.
2.36 in.
8.23 in.
8.23 in.
3.65 in.
3.65 in.
8.63 in.
8.63 in.
WEB VERSION
