Ref Value
(Current Input)
4..20 mA = 0..10000 rpm (speed mode)
4..20 mA = 0..100% (process mode)
- Grounds are internally connected.
- Direct connection, no protection.
Galvanic isolation on the user side is
required.
- Default input settings:
Current inputs selected. Voltage input
can be selected with EEPROM–editor in
Service Software (consult detailed
firmware spec. and Service Software
Manual with doc.# PL-2034-00)
Actual Process
Control Value
(Current Input)
Ref Value
(Voltage Input)
0..10 V = 0..10000 rpm
- Speed Limit = 8000 rpm 8 V
- Cut-off (min.) speed = 300 rpm
0..10 V mA = 0..100% (process mode)
Actual Process
Control Value
(Voltage Input)
Direct connection, no protection.
Galvanic isolation on the user side is
required.
5V is given by standard firmware,
hardware allows up to 10V output.
Actual Process
Control Value
24 V active
0 V not active
24 V active
0 V not active
Switches between process mode and
speed mode.
24 V active, system on
0 V not active, system off
The Enable signal switches the pump
system on and off.
Relay closed active, system on
Relay open not active, system off
This signal indicates the state of the
pump system.
Relay closed not active, system on
Relay open active, system off
When active, the system drives the
impeller to zero rpm and shuts down.
With a reset pulse the system can be re-
initialized.
Relay closed not active, system o.k.
Relay open active, system not o.k.
The warning signal indicates if a system
fault has been detected. The warning
signal indicates a system fault but the
system does not shut down
DefaultSetting:
Trend Warning
Option:
Priming Valve
Signal
Relay closed warning active
Relay open warning not active
Relay closed warning active
Relay open warning not active
Default setting: Relay closed if trend
warning is active. Can be changed in
EEPROM with Service Software
Can be used to control a priming valve
for priming of the pump. Feature can be
activated and configured with Service
Software.
Table 14: Signals of the PLC connector for standard firmware E1.48 and E2.48
(For other configurations of PLC inputs and outputs refer to alternate firmware documentation.)
