Lexmark 21J0380 - X 772e MFP Color Laser Technical Reference Manual

Supported bar codes
124
RSS (Reduced
Space Symbology)
Y
3
YYYY RSS-14 is a linear symbology that facilitates
omnidirectional scanning. It encodes 14 digits of
numerical data used to identify Global Trade Item
Numbers (GTIN) in the supply chain.
RSS-14 Truncated allows truncation (shortening the
height of a bar code) of the height to 13 times the
nominal printing density (X dimension multiplied by
13) instead of 33X.
RSS-14 Stacked allows the truncated RSS-14 to be
printed in two rows of two segments each.
RSS Limited uses a different encoding process and
limits the values assigned for indicator digits to 1 or
0.
RSS Expanded is a variable length, linear
symbology that is encoded differently than RSS-14.
This symbology allows up to 74 numeric or 41
alphabetic characters.
RSS-14 Stacked Omnidirectional allows the full
height RSS-14 to be printed in two rows of two
segments each.
Bar code name
Lexmark Forms and Bar Code Card v3.0 Lexmark Forms and Bar Code Card v3.1 Lexmark Forms and Bar Code Card v3.2 LDSS Forms Composer v3.3.9 LDSS Document Producer Lexmark Optra Forms
Sample image Comments
1 PDF417 and MaxiCode can be printed using Optra Forms only when the bar code option is also installed in the printer, and when the accompanying bar code
dictionaries have been installed in Optra Forms.
2 All one-dimensional bar code symbologies supported by the Bar Code Card version 2.4 or later can be printed with Optra Forms
when the bar code option is
installed in the printer, and the accompanying bar code dictionaries is installed in Optra Forms.
3 These bar codes are not available in PCL 5 or PostScript.
