Arguments for MaxiCode bar code symbology
93
MicroPDF417
Key Type Range Default value Description
/Symbology name n/a n/a Required
Identifies the bar code symbology
(/MicroPDF417)
/Units name /300ths
/600ths
/1200ths
/600ths Optional
/Units is used for /ModuleWidth and
/ModuleHeight calculations.
/ModuleWidth int 240–12000 (dec) 945 (dec)
03 B1 (hex)
Optional
Sets the X dimension of the module
(white or black rectangle) in 100th of an
inch. To set the X dimension to default at
600 dpi requires a value of 9.45, which is
specified here as 945 decimal.
Note: Values beyond the defined range
are appropriately clipped and set to the
minimum and maximum values.
/ModuleHeight int 480–60000 (dec) 1890 (dec)
07 62 (hex)
Optional
Sets the Y dimension of the module
(white or black rectangle) in 100th of an
inch. To set the Y dimension to “default”
at 600 dpi requires a value of 18.9, which
is specified here as 1890 decimal.
Notes:
• The range of Y dimension is
dependent on the value of X
dimension, such that,
Min=2 * X dimension, and
Max=5 * X dimension.
• Values beyond the defined range
are appropriately clipped and set to
the minimum and maximum values.
/Rows int 4–44 (dec) 0 (dec)
00 (hex)
Optional
This is an automatic operation specified
by using 0.
/Columns int 1–4 (dec) 0 (dec)
00 (hex)
Optional
This is an automatic operation specified
by using 0.
