Composite bar codes
62
PCL specifications for composite bar codes
Field Name Type Range
Default (if not
specified)
Definition
Symbology ID int — — Required
24600T specifies UPC-A
24601T specifies UPC-A+2
24602T specifies UPC-A+5
24610T specifies UPC-E
24611T specifies UPC-E+2
24612T specifies UPC-E+5
24620T specifies EAN-8
24621T specifies EAN-8+2
24622T specifies EAN-8+5
24630T specifies EAN-13
24631T specifies EAN-13+2
24632T specifies EAN-13+5
24710T specifies UCC-128
24810T specifies RSS-14
24811T specifies RSS-14 Truncated
24812T specifies RSS-14 Stacked
24814T specifies RSS-14 Limited
24815T specifies RSS-14 Expanded
Module Height (of
the linear
component)
int Dependent on the
module height
range of the linear
component.
Dependent on the
default module
height of the linear
component.
Corresponds to HP #v parameter
Module Width (of
the linear
component)
int Dependent on the
module width
range of the linear
component.
Dependent on the
default module
width of the linear
component.
Corresponds to the HP #b parameter
The dimensions of the composite bar code may be varied in only two directions.
• The module height of the linear component is varied using the V parameter.
• The module width of the linear component is varied using the B parameter.
