Two-dimensional bar codes
87
PLANET Codes
Note: For more information on the specifications implemented on the PLANET code, refer to
Appendix B and C of the USPS PLANET Specifications.
/EmbedText name /NoText
/Under
/Above
/NoText Optional
Defines if and where the HRT is to
be printed
/FontName name See these
sections:
•Values for
/EmbedText key
•Values for
/FontName key
/Courier-Bold Optional
Defines how the HRT is to be printed
When the value given is not within
the defined range:
• If the value is of type name, then
the value will be set to default (/
Courier-Bold)
• If the value is of any other type,
then a TYPECHECK error will be
returned.
/QuietZone [int int] Minimum:
[0 0] (dec)
Maximum:
[1200 1200] (dec)
[150 150] (dec)
[96 96] (hex)
Optional
Note: Values less than the minimum
use the default value of [150 150].
Key Type Range Default value Description
/Symbology name n/a n/a Required.
Identifies the bar code symbology
(/PLANET.
/Pitch int 20–24 (dec) • 22 (dec)
or
• 16 (hex)
Optional
Selects the bar pitch of the PLANET bar
code
Values less than 20 (dec) or 14 (hex)
result in a pitch of 20. Values greater
than 24 (dec) or 18 (hex) result in a
pitch of 24.
/QuietZone [int int] Minimum:
[0 0] (dec)
Maximum:
[1200 1200]
(dec)
• [150 150]
(dec)
or
• [96 96]
(hex)
Optional
Note: Values less than the minimum
use the default value of [150 150].
Key Type Range Default value Description
