One-dimensional bar codes
47
Intelligent Mail
Note:
• Intelligent Mail is called from PCL using the block-call method.
Bytes Field Name Type Range Default value Definition
0–1 Symbology ID name n/a 25 (dec)
00 19(hex)
Required
Specifies Intelligent Mail bar
code symbology
2 Bar Width — 38–63 (dec)
26–3F (hex)
50 (dec)
16 (hex)
Optional
Sets the bar width to 1/100
mm
3 Bar Pitch — 20–24 (dec)
14–18 (hex)
23 (dec)
17 (hex)
Optional
Specifies X-dimesion of the
bar pitch
4 Tracker Height — 100–160 (dec)
64–A0 (hex)
127 (dec)
7F (hex)
Sets the tracker height to 1/
100 mm
5 Ascender,
Descender
Offset
— 100–210 (dec)
64–D2 (hex)
135 (dec)
87 (hex)
Sets the ascender and
descender offset in 1/100
mm
The total height of the
ascender or descender is
the sum of this field and the
tracker height.
6 HRT Location 0—Default (No Text)
1—No Text
2—Embedded
3—Half Embedded
4—Under
5—Above
1 Optional.
This determines the location
of human-readable text
printed with the bar code.
Note: Intelligent Mail uses
only the values 1, 4, and 5.
Other values not specified
will be replaced with 1.
7–15 Reserved — — — These bytes are ignored.
