Lexmark 21J0380 - X 772e MFP Color Laser Technical Reference Manual

One-dimensional bar codes
21
Field Name Type Range
Default
(if not specified)
Description
Esc (s#T name n/a n/a Required
• 24810T specifies
RSS-14 Standard
• 24811T specifies
RSS-14 Truncated
• 24812T specifies
RSS-14 Stacked
• 24814T specifies
RSS-14 Limited
• 24815T specifies
RSS-14 Expanded
Esc(s#V int Minimum:
Minimum value is 3
(dec) or 03 (hex)
Maximum:
There is no maximum
value, but larger bar
codes use up more
memory.
Standard:
33 (dec) or 21 (hex)
Truncated:
13 (dec) or 0D (hex)
Stacked (total height):
13 (dec) or 0D (hex)
Limited:
10 (dec) or 0A (hex)
Expanded:
34 (dec) or 22 (hex)
Optional
Selects the height of the
bars in 1/72” (same
units as fonts).
Note: Values lesser
than the minimum uses
the corresponding
default value for the
specific RSS bar code
type.
Esc(s#1,#2,#3,#4B int Minimum:
Minimum value is 1, but
symbol may be too
small to be readable.
Maximum:
There is no maximum
value but larger bar
codes use up more
memory.
8,16,24,32 (dec)
or
8,10,18,20 (hex)
Optional
Selects the width of the
bars.
