Bar code descriptor for MicroPDF417
55
4–5 X
dimension
byte 1 (in
units)
X dimension
byte 2 (in
units)
240–12000 (dec) 945 (dec)
03 1 (hex)
Optional
Sets the X dimension of the
module (white or black rectangle)
in 100th of an inch.
Note: Values that go beyond the
defined range are appropriately
clipped and set to the minimum
and maximum values.
To set the X dimension to default
at 600 dpi requires a value of 9.45,
which is specified as 945 (dec) or
03 B1 (hex).
The Units enumeration will be set
to 02 or 00 (hex), and these two
bytes will be 03 and B1 (hex).
6–7 Y
dimension
byte 1 (in
units)
Y dimension
byte 2 (in
units)
480–60000 (dec)
Note: The range
of Y dimension is
dependent on the
value of X
dimension, such
that Min=2 *
X-dimension
Max=5 *
X-dimension
1890 (dec)
07 62 (hex)
Optional
Note: The range of values of the Y
dimension is between 2 to 5 times
the values of the X dimension. Any
value beyond that range will be
clipped appropriately and set to
the minimum and maximum
values.
Sets the Y dimension of the
module (white or black rectangle)
in 100th of an inch.
The default width of this element
from the bar code engine is twice
that of the X dimension. To set the
Y dimension to default at 600 dpi
requires a value of 18.9, which is
specified as 1890 (dec) or 07 62
(hex).
The Units enumeration will be set
to 02 or 00 (hex), and these two
bytes will be 07 and 62 (hex). If not
specified, the Y dimension will
become double that of the X
dimension.
8–9 Rows Columns Rows:
4–44 (dec)
Columns:
1–4 (dec)
0 (dec)
00 (hex)
Optional
Manually set the number of
symbol rows. Automatic operation
is specified by using 0.
Manually set the number of
symbol columns. Automatic
operation is specified by using 0.
10–15 Reserved — — — —
Bytes MSB LSB Range
Default (if not
specified)
Definition
