Note: If you have installed the optional Auto Sheet Feeder or Tractor 2, then see the documentation that came with
your option for paper loading instructions.
1 Plug the printer power cord to a properly grounded electrical outlet, and then press Start/Stop.
2 Make sure the paper path is clear.
Note: If a cut form or envelope is loaded in the printer, then press FormFeed to remove it.
3 Set the forms thickness lever to a setting corresponding with the paper thickness you are using.
4 Remove the ribbon access cover.
5 Move the paper select lever down to the position.
6 Pull up the left and right tractor locking levers to unlock the tractors.
Loading paper 28
