Converting the push tractor to pull tractor position
1 Make sure the printer is unplugged from the electrical outlet.
2 Make sure paper is not loaded in the printer.
3 Pull the front cover up and out of the way.
4 Hold down the latching levers while you lift and pull out the tractor unit from the printer.
1
2
1 Tractor unit
2 Latching levers
5 Remove the ribbon access cover.
6 Turn the tractor unit around so that the latching levers are upright, facing you.
7 Place the tractor against the back slant of the printer along the tractor guides.
Changing tractor positions 44
