Maintaining the printer
Periodically, certain tasks are required to maintain optimum print quality.
Ordering supplies
Use the following part numbers to order printer supply items you will need.
Supply item Part number
Parallel cable
• 1329605 (10‑foot cable)
• 1427498 (20‑foot cable)
USB cable 12A2405
Serial adapter and cable
• 12T0154 (Serial Interface option)
• 1038693 (50‑foot cable)
Printer ribbon
• 3070166 (2400/2500/250 series standard re‑inking ribbon)
• 3070169 (2500/2500+ series high yield re‑inking ribbon)
Note: Printer ribbons can be ordered at
www.lexmark.com.
Removing the ribbon cartridge
1 Unplug the printer power cord from the electrical outlet.
2 Lift the left and right release latches on the ribbon access cover to remove it.
3 Place the ribbon access cover on a flat surface.
4 Set the forms thickness lever to position 7.
5 Squeeze the left and right latches on the ribbon cartridge to lift it out of the printer.
Cleaning the printer
Preparing the printer for cleaning
1 Unplug the printer power cord from the electrical outlet.
CAUTION—HOT SURFACE: The printhead may be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching it.
2 Squeeze the left and right latches on the ribbon cartridge, and then lift it out of the printer.
Cleaning the inside of the printer
• Every few months, use a soft brush and a vacuum to remove dust, ribbon lint, and pieces of paper from the printer.
• Vacuum any dust from around the printhead and from inside the printer.
Maintaining the printer 56
