2 Attach the gray data cable to the printer RIP card as shown, and then tighten the two screws.
3 Attach the scanner power cable to the printer.
Connecting your printer to a single computer or to a network of
computers
Decide if the printer needs to be connected to just one computer (local) or to many computers on network (network).
Setting the printer up with local setup
Local printing is printing to a locally attached printer (a printer that is connected directly to your computer with a USB
or parallel cable). When setting up this type of printer with a USB cable, you should install the printer software
before connecting the USB cable.
The Software and Documentation CD can be used to install the necessary printer software on most Windows
operating systems.
1 Insert the CD.
23
