Supported bar codes
119
Interleaved 2 of 5 YYYYYYY Interleaved 2 of 5 encodes digit pairs in an
interleaved manner.
Each data character is composed of five elements,
either five bars or five spaces. Of these five
elements, two are wide and three are narrow. Each
digit has its own unique 2 out of 5 arrangement.
A complete Interleaved 2 of 5 symbol consists of the
start code (two narrow bars and two narrow
spaces), the data characters, and the stop code
(one wide bar, a narrow space, and a narrow bar).
For general-purpose, free-form numeric data, this is
the most efficient code available.
Interleaved 2 of 5 has no built in checksum.
Interleaved 2 of 5 +
check digit
YYYYYYY Interleaved 2 of 5 optionally allows for a weighted
Modulo 10 check character for special situations
where data security is important.
ITF14 Y Y
3
Y Y Y Y ITF-14 is an Interleaved 2 of 5 bar code with bearer
bars surrounding the bar code.
Bar code name
Lexmark
Forms and Bar
Code Card v3.0
Lexmark
Forms and Bar
Code Card v3.1
Lexmark
Forms and Bar
Code Card v3.2
Lexmark
Forms and Bar
Code Card v3.3
LDSS Forms
Composer
v3.3.9
LDSS
Document
Producer
Lexmark
Optra Forms
Sample image Comments
1 PDF417 and MaxiCode can be printed using Optra Forms only when the bar code option is also installed in the printer, and when the accompanying bar code dictionaries
have been installed in Optra Forms.
2 All one-dimensional bar code symbologies supported by the Bar Code Card version 2.4 or later can be printed with Optra Forms
when the bar code option is installed in
the printer, and the accompanying bar code dictionaries is installed in Optra Forms.
3 These bar codes are not available in PCL 5 or PostScript.
