Lexmark MS810n Technical Reference Manual

Arguments for one-dimensional bar codes
78
Arguments for one-dimensional bar codes
Key Type Definition
/Symbology name Required
See “Values for /Symbology key” on page 80 for valid values.
/Units — Optional
Default value is 1/600 inch. Other valid values are 1/300, 1/1200,
and 1/720 inch, which also applies to height and width units for
any one-dimensional symbology.
/Height integer Optional
In /Units; the default value is based on the symbology, see
“Values for /Symbology key” on page 80.
/QuietZone [int int] Optional
In /Units; the default value is [150 150].
/Bars [int int int int] Optional
In /Units; the default value is based on the symbology, see
“Values for /Symbology key” on page 80.
/Spaces [num num num num] Optional
In /Units; the default value is based on the symbology, see
“Values for /Symbology key” on page 80.
/EmbedText name or
[name name]
Optional
The default is based on the symbology, see
“Values for /EmbedText key” on page 83. [array] is used by ISSN
and ISBN only.
/FontName name Optional
See “Values for /FontName key” on page 83. The default value is
Courier-Bold.
/Pitch [int] Optional
This is used only by PostNet5, PostNet9, and PostNet11 bar
codes.
Allowed values are 20 through 24. Values less than 20 result in a
pitch of 20, values greater than 24 result in a pitch of 24. Default
is 22.
1
For the French postal symbology, /Special and /PrintCheckChar are always set to true and cannot be
changed to false.

Lexmark MS810n Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4.8 s
Print speed (black, normal quality, A4/US Letter)	52 ppm
Network ready	Yes
Security algorithms	LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black
Maximum duty cycle	250000 pages per month
Recommended duty cycle	3000 - 20000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XML
Internal memory	512 MB
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	57 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supported	Fedora 14, Fedora 15, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	55 W
Power consumption (printing)	700 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CSA, ICES, BSMI, CNS, VCCI, US, FDA, FCC, IEC, CE, GS, TUV, SEMKO, SMA, CCC, CISPIR, ECMA, TED
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Weight	23660 g
Dimensions (WxDxH)	425 x 419 x 510 mm
