Lexmark MS810n Technical Reference Manual

Two-dimensional bar codes
31
Two-dimensional bar codes
Bar code descriptor for Codablock F
HP BarDIMM deviations:
The HP BarDIMM Pro uses the PCL 5 height command V1 to specify the single line bar height of the
Codablock F bar code, such as the height of one of the rows contained in the bar code. No provision
is made to specify the absolute height of the Codablock F symbol. Parameters V2 and V3 are
derived from the ELMICRON specification.
In the HP BarDIMM Pro specification, the Codablock V parameter #1 is the single line bar height in 1/
60”, but it is actually in 1/72”.
Field Name Type Range
Default
(if not specified)
Description
Esc (s#T name na n/a Required
24840T
Esc
(s#1,#2,[#3]V
Int Minimum: 
3 (dec) or 03 (hex)
Maximum: 
There is no maximum
value.
16 (dec) or 10 (hex) Optional
Selects bar height
bar height to 1/72”
(same units as fonts)
Note: Values from 0 to
2 are the same as the
default.
Int Minimum: 
2 rows
Maximum: 
44 rows
2 (dec) or 02 (hex) Optional for Forms and
Bar Code Card,
required for HP
BarDIMM. (See
“Deviations” chapter)
Requested number of
rows in the Codablock F
symbol.
Int Minimum: 
4 columns
Maximum: 
103 columns
20 (dec) or 14 (hex) Optional
Requested number of
columns in the
Codablock F symbol
Esc (s#1]B Int Minimum:
Minimum value of B1 is
1, but it may be
unreadable.
Maximum:
There is no maximum
value for B1, but larger
bar codes use up more
memory.
6 (dec) or 06 (hex) Optional
Selects bar width

Lexmark MS810n Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4.8 s
Print speed (black, normal quality, A4/US Letter)	52 ppm
Network ready	Yes
Security algorithms	LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black
Maximum duty cycle	250000 pages per month
Recommended duty cycle	3000 - 20000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XML
Internal memory	512 MB
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	57 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supported	Fedora 14, Fedora 15, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	55 W
Power consumption (printing)	700 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CSA, ICES, BSMI, CNS, VCCI, US, FDA, FCC, IEC, CE, GS, TUV, SEMKO, SMA, CCC, CISPIR, ECMA, TED
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Weight	23660 g
Dimensions (WxDxH)	425 x 419 x 510 mm
