One-dimensional bar codes
22
PCL 5 function parameter list
Command Function/Parameters (#v units are in 1/72”; #b, s units are in 1/600”)
Esc
(s#T
or
AEC
)s#T
Selects the bar code
symbology
Default parameters
1
Characters encoded Symbol
2
length Checksum character
Typeface # Bar code symbology #v #p #b1,
s1
#b2,
s2
#b3,
s3
#b4,
s4
23591 USPS Zebra 22.5* 1 112* ———N—No
24600 UPC-A 74.4 3 8 16 24 32 N 11 Yes
3
24601 UPC-A with 2-digit
supplemental
74.43 8 162432N13Yes
3
24602 UPC-A with 5-digit
supplemental
74.43 8 162432N16Yes
3
24610 UPC-E 28.8 3 8 16 24 32 N 6 Yes
3
24611 UPC-E with 2-digit
supplemental
28.83 8 162432N8 Yes
3
24612 UPC-E with 5-digit
supplemental
28.83 8 162432N11Yes
3
24620 EAN/JAN-8 50.43 8 162432N7 Yes
3
24621 EAN/JAN-8 with 2-digit
supplemental
50.43 8 162432N9 Yes
3
24622 EAN/JAN-8 with 5-digit
supplemental
50.43 8 162432N12Yes
3
24630 EAN/JAN-13 74.4 3 8 16 24 32 N 12 Yes
3
24631 EAN/JAN-13 with 2-digit
supplemental
74.43 8 162432N14Yes
3
24632 EAN/JAN-13 with 5-digit
supplemental
74.43 8 162432N17Yes
3
24640 Interleaved 2 of 5 28.8 1 6 18 — — N even No
24641 Interleaved 2 of 5 with check
digit
28.8 1 6 18 — — N odd Yes
24642 German Postal 2 of 5
Leitcode
72.0 124 10 30 — — N 13 Yes
1
For all bar code symbologies, the default value of the #H
text font parameter is CBA = 000 (automatically sized
Courier Bold).
2
Does not include checksum character
3
Checksum character is always printed if embedded text
is specified.
* = Fixed value, cannot be changed
N = Numeric
M = Mixed

Lexmark MS810n Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4.8 s
Print speed (black, normal quality, A4/US Letter)	52 ppm
Network ready	Yes
Security algorithms	LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black
Maximum duty cycle	250000 pages per month
Recommended duty cycle	3000 - 20000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XML
Internal memory	512 MB
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	57 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supported	Fedora 14, Fedora 15, SuSE Linux 10.3, SuSE Linux 11
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	55 W
Power consumption (printing)	700 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CSA, ICES, BSMI, CNS, VCCI, US, FDA, FCC, IEC, CE, GS, TUV, SEMKO, SMA, CCC, CISPIR, ECMA, TED
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Weight	23660 g
Dimensions (WxDxH)	425 x 419 x 510 mm
