Page #235 background imageLoading...
Page #235 background image
Action Yes No
Step 7
Increase the scan resolution settings for a higherquality output.
Did the increased resolution produce a higherquality output?
Problem solved. Contact
customer
support.
Partial document or photo scans
Action Yes No
Check the placement of the document or photo.
Make sure the document or photo is loaded facedown on the
scanner glass in the upper left corner.
Is the document or photo loaded correctly?
Contact
customer
support.
Load the document
or photo facedown
on the scanner glass
in the upper left
corner.
Embedded Web Server does not open
Action Yes No
Step 1
a Turn on the printer.
b Open a Web browser, and then type the printer IP address.
c Press Enter.
Does the Embedded Web Server open?
The problem is
solved.
Go to step 2.
Step 2
Make sure the printer IP address is correct.
a View the printer IP address:
From the TCP/IP section in the Network/Ports menu
By printing a network setup page or menu settings page,
and then finding the TCP/IP section
Note: An IP address appears as four sets of numbers
separated by periods, such as 123.123.123.123.
b Open a Web browser, and then type the IP address.
Note: Depending on the network settings, you may need to
type “https://” instead of “http://” before the printer IP
address to access the Embedded Web Server.
c Press Enter.
Does the Embedded Web Server open?
The problem is
solved.
Go to step 3.
Troubleshooting 235

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MX317dn and is the answer not in the manual?

Lexmark MX317dn Specifications

General IconGeneral
CertificationENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Envelopes sizes7 3/4, 9, 10, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Copier resize25 - 400 %
Maximum copy resolution- DPI
Duplex copy speed (black, US Letter)17 ppm
Copy speed (black, normal quality, A4)33 cpm
Scan toE-mail, FTP, USB
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Scan speed (black)42 ppm
Scan speed (color)19 ppm
Image formats supportedJPG, TIF
Document formats supportedPDF, XPS
Optical scanning resolution (black)1200 x 600 ppi
Optical scanning resolution (color)600 x 600 ppi
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax transmission speed3 sec/page
Digital senderNo
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle250 - 6000 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Cabling technology10/100Base-T(X)
Security algorithmsSNMPv3
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP
DisplayLCD
Product colorBlack, Grey
Display diagonal2.4 \
Market positioningBusiness
Display number of lines2 lines
Internal memory256 MB
Processor cores2
Processor frequency800 MHz
Sound pressure level (copying)54 dB
Sound pressure level (printing)53 dB
Sound pressure level (scanning)55 dB
Sound pressure level (quiet mode)49 dB
USB connectorUSB Type-B
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (off)0.4 W
Power consumption (ready)9 W
Power consumption (sleep)3.2 W
Power consumption (copying)540 W
Power consumption (printing)520 W
Power consumption (scanning)20 W
Power consumption (average operating)- W
Energy Star Typical Electricity Consumption (TEC)1.8 kWh/week
Sustainability certificatesBlue Angel, ENERGY STAR
Package depth550 mm
Package width485 mm
Package height571 mm
Package weight22500 g
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Paper input typePaper tray
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity850 sheets
Maximum number of input trays3
Auto document feeder (ADF) input capacity50 sheets
Included cartridge capacity (black)2500 pages
Weight and Dimensions IconWeight and Dimensions
Depth472 mm
Width399 mm
Height468 mm
Weight20000 g
