To optimize performance and minimize jams, do not use envelopes that:
Have excessive curl or twist
Are stuck together or damaged in any way
Have windows, holes, perforations, cutouts, or embossing
Have metal clasps, string ties, or folding bars
Have an interlocking design
Have postage stamps attached
Have any exposed adhesive when the flap is in the sealed or closed position
Have bent corners
Have rough, cockle, or laid finishes
Adjust the width guides to
fit
the width of the envelopes.
Note: A combination of high humidity (over 60%) and high printing temperature may wrinkle or seal
envelopes.
Tips on using labels
Print samples on the labels being considered for use before buying large quantities.
Note: Use only paper label sheets. Vinyl, pharmacy, and twosided labels are not supported.
For more information on label printing, characteristics, and design, see the Card Stock & Label Guide available
at
http://support.lexmark.com.
When printing on labels:
Use labels designed
specifically
for laser printers. Check with the manufacturer or vendor to verify that:
The labels can withstand temperatures up to 240°C (464°F) without sealing, excessive curling, wrinkling,
or releasing hazardous emissions.
Label adhesives, face sheet (printable stock), and topcoats can withstand up to 172kPa (25psi) pressure
without delaminating, oozing around the edges, or releasing hazardous fumes.
Do not use labels with slick backing material.
Use full label sheets. Partial sheets may cause labels to peel o during printing, resulting in a jam. Partial
sheets also contaminate the printer and the cartridge with adhesive, and could void the printer and toner
cartridge warranties.
Do not use labels with exposed adhesive.
Do not print within 1 mm (0.04 inch) of the edge of the label, of the perforations, or between diecuts of the
label.
Make sure the adhesive backing does not reach to the edge of the sheet. Zone coating of the adhesive
should be at least 1 mm (0.04 inch) away from edges. Adhesive material contaminates the printer and could
void the warranty.
If zone coating of the adhesive is not possible, then remove a 2mm (0.08inch) strip on the leading and
driver edge, and then use a nonoozing adhesive.
Portrait orientation is recommended, especially when printing bar codes.
Paper and specialty media guide 43

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark MX317dn and is the answer not in the manual?

Lexmark MX317dn Specifications

General IconGeneral
CertificationENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Envelopes sizes7 3/4, 9, 10, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)33 ppm
Copier resize25 - 400 %
Maximum copy resolution- DPI
Duplex copy speed (black, US Letter)17 ppm
Copy speed (black, normal quality, A4)33 cpm
Scan toE-mail, FTP, USB
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Scan speed (black)42 ppm
Scan speed (color)19 ppm
Image formats supportedJPG, TIF
Document formats supportedPDF, XPS
Optical scanning resolution (black)1200 x 600 ppi
Optical scanning resolution (color)600 x 600 ppi
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax transmission speed3 sec/page
Digital senderNo
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle250 - 6000 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Cabling technology10/100Base-T(X)
Security algorithmsSNMPv3
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP
DisplayLCD
Product colorBlack, Grey
Display diagonal2.4 \
Market positioningBusiness
Display number of lines2 lines
Internal memory256 MB
Processor cores2
Processor frequency800 MHz
Sound pressure level (copying)54 dB
Sound pressure level (printing)53 dB
Sound pressure level (scanning)55 dB
Sound pressure level (quiet mode)49 dB
USB connectorUSB Type-B
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (off)0.4 W
Power consumption (ready)9 W
Power consumption (sleep)3.2 W
Power consumption (copying)540 W
Power consumption (printing)520 W
Power consumption (scanning)20 W
Power consumption (average operating)- W
Energy Star Typical Electricity Consumption (TEC)1.8 kWh/week
Sustainability certificatesBlue Angel, ENERGY STAR
Package depth550 mm
Package width485 mm
Package height571 mm
Package weight22500 g
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Paper input typePaper tray
Total input capacity300 sheets
Total output capacity150 sheets
Maximum input capacity850 sheets
Maximum number of input trays3
Auto document feeder (ADF) input capacity50 sheets
Included cartridge capacity (black)2500 pages
Weight and Dimensions IconWeight and Dimensions
Depth472 mm
Width399 mm
Height468 mm
Weight20000 g
