One-dimensional bar codes
44
6-7 Bar Height int 150-600 (dec) • 240 (dec)
or
•00 F0 (hex)
Optional.
Corresponds to HP #v parameter in
the specified Bar Height units.
Note: Values that go beyond the
defined range will be appropriately
clipped and set to the minimum and
maximum values.
The default HIBC Bar Height is 0.4
inches. If byte 5 is default 00 (600
dpi), then the Bar Height is 240 Bar
Height Units, which is 00 F0 hex.
8 Bar/Space Width
Units
int 0=Default
(1/600” units)
1=1/300”
units
2=1/600”
units
3=1/1200”
units
• 0 or 2 (dec)
or
• 00 or 02
(hex)
Optional.
Specifies units for Bar and Space
widths.
9-10 Bar Width #1
(Code 128 bar 1,
or Code 39
Narrow)
int 5-27 (dec) • 6 (dec)
or
• 00 06 (hex)
Optional.
Note: Values that go beyond the
defined range will be appropriately
clipped and set to the minimum and
maximum values.
The default HIBC 128 bar 1 and
HIBC 39 narrow bar widths are both
0.01 inches. If byte 5 is default 00
(600 dpi), then the Bar Width is 6,
which is 00 06 hex.
11-12 Space Width #1
(Code 128 space
1, or Code 39
Narrow)
int 5-27 (dec) • 6 (dec)
or
• 00 06 (hex)
Optional.
Note: Values that go beyond the
defined range will be appropriately
clipped and set to the minimum and
maximum values.
The default HIBC 128 space 1 and
HIBC 39 narrow space widths are
both 0.01 inches. If byte 5 is default
00 (600 dpi), then the Space Width
is 6, which is 00 06 hex.
Byte Field name Type Range Default value Description
