One-dimensional bar codes
45
ITF-14
Byte Field name Type Range Default value Description
0-1 Symbology ID int int n/a • 103 (dec)
or
• 00 67 (hex)
Required.
Specifies ITF-14 symbology.
2 HRT Location int 0=Default
(No HRT)
1=No HRT
4=Under
5=Above
• 0 or 1 (dec)
or
• 00 or 01
(hex)
Optional.
Corresponds to the HP #p
parameter.
3 HRT Typeface int 0=Courier
1=SM Gothic
2=SM Unit
3=SM Unit
Condensed
4=Roman
5=OCRB
•0 (dec)
or
•00 (hex)
Optional.
Corresponds to the HP #h
parameter.
Note: When the value given is not
within the defined range, the value
will be set to default (Courier).
4 HRT Style int 0=Regular
1=Italic
2=Bold
3=Bold Italic
•2 (dec)
or
•02 (hex)
Optional.
Specifies the font style used for
HRT.
Note: Default font style for OCRB is
Regular only.
5 Bar Height Units int 0=default
(1/600” units)
1=1/300”
units
2=1/600”
units
3=1/1200”
units
•2 (dec)
or
•02 (hex)
Optional.
Specifies units for bar height
dimensions.
6-7 Bar Height [int int] Min: 307
(dec) or 01 33
(hex)
Max: There is
no maximum
value.
• 756 (dec)
or
•02 F4 (hex)
Optional.
Corresponds to HP #v parameter in
the specified Bar Height units.
Note: Values that go beyond the
defined range will be appropriately
clipped and set to the minimum
value.
The default BCE ITF-14 Bar Height
is 1.25984 inches. If byte 5 is default
00 (600 dpi), then the Bar Height is
755.9 (or 756) Bar Height Units,
which is 02 F4 hex.
