FREESCAPE emulation
65
The # represents the ASCII code of the AEC. Use one of the ASCII codes listed:
Example:
FREESCAPE emulation can be deactivated by setting the AEC value to that of the escape character
(decimal 27, hex 1B). To deactivate FREESCAPE emulation, send the command:
AEC
**27J.
To set an AEC from the printer control panel:
1 From the Forms Card menu, select Alt ESC Code.
2 Select On to enable the AEC.
3 From the Forms Card menu, select Alt ESC Code Char.
4 Select an AEC from the menu.
You can disable the AEC by selecting Off from the Alt ESC Code menu.
Command Function/Parameter
Esc
**#J
or
AEC
**#J
ASCII code Character
34 “
35 #
36 $
47 /
63 ?
92 \
123 {
124 |
125 }
126* ~
* Default value
Esc
**124J changes the AEC to “|”
